Diag4 Bike Serial Diagnostic System Software With Bluetooth Interface – AT 531 5091

Description

Professional diagnostic tool for Harley Davidson & Buell workshops and tuning centers. Diagnoses electronic fuel injection module (EFI) and others (Security modules, ABS, etc.) through the diagnostic connector. The system consists of a communication interface with Harley-Davidson adapter, USB cable for connection to your Laptop (PC) and software compatible with Windows XP, Vista, 7, 8 and 10. A wireless Bluetooth version of the interface is also available. An adapter for CAN-BUS models is included. The system performs the following functions and more. Software for Indian and Victory is also available.FeaturesIgnition ModuleEFI (Electronic Fuel Injection Module) – All modelsTSSM (Turn Signal Security Module)…………..Key FOB with buttonHFSM (Hands Free Security Module)………….Key FOB without buttonBCM (Body Control Module)………….Key FOB without buttonGauges (Speedo, Tach and Instrument Module) – All modelsABS Module (Delphi + CAN models) – All modelsRadio and Audio all modelsThunder MAX EFIRead and Clear Diagnostic Trouble Codes………………….All modelsRead Identification data (part numbers, VIN number)……All modelsMonitoring real-time data (throttle position, temperature, oxygen sensors, turn signals etc.)Test actuators (injectors, coils, main relay, fuel pump, idle, turn signals, tachometer, lamps etc.)Buell diagnostics are incorporated in Harley-Davidson diagnosticsUnit of measure selection metric/standardCommunication interface is CAN ready (models with 6-pin connector)Module replacement –TSM, TSSM, HFSM, BCM,ABS Service (Bleeding and configuration, Delphi + CAN models) – All modelsACR (Automatic compression release during starting)Cruise Control, Exhaust actuator, EITMS……enable/disableSide Stand Switch Configuration – All ModelsIntake Solenoid Valve Configuration on CAN ModelsRadio customization-region code and speaker configuration, radio pairingJ&M Audio ConfigurationABS Telltale Configuration on CAN ModelsIdle speed adjustment 800 – 1200 rpm (models with Delphi Electronic Fuel Injection Module)TSSM Customization……PIN read/change, Auto arming disable/enable etc.HFSM Customization……Key FOB assignment/replacement, Auto arming disable/enable, PIN read/change, Side car and Service Mode (disable/enable)BCM Customization……..Key FOB assignment/replacement, Auto arming disable/enable, PIN read/change, Lights configuration, keyless ignitionDisarming (HFSM/BCM module)……..PIN read/FOB assignment on armed bike (for BCM modules a CAN disarming cable is needed)Buell TPS adjustmentDatalogingABS Module (embedded/not embedded)Speedo module pairingWheel size adjustment (Speedo calibration)Odometer unit setting
