Double Flange Wheel Hub 2.5″ & 58mm Bolt Circles | Single-Use Hub*

Description

Dual Flange Wheel Hub Specs:

• Brand: BMI Karts
• Material: Aluminum
• Lightweight
• Hub Style: Front / Dead Axle
• 58mm & 2.5″ Bolt Circles (Metric & American)
• Wheel Bolt Patterns:
  (3) 1/4-28 Bolt Holes on a 2-1/2″ Bolt Circle
  (3) 5/16-24 Bolt Holes on a 2-1/2″ Bolt Circle
  (3) M8-1.25 Bolt Holes on a 58mm Bolt Circle
• Brake / Sprocket Bolt Patterns:
  (6) M6 x 1.0 Threaded Holes on a 50mm Bolt Hole Circle
  (3) 5/16-24 Bolt Holes on a 2-3/8″ Bolt Hole Circle
• Fits Bearing OD: 1-3/8″
• Overall Width: 3.35″

Compatibility / Use:

• Single Wheel Drive (use adapter plate to use 35 split sprocket)
• Single Wheel Front / Rear Brake
• Front Brake Disc Hub pair with  MCP506 – Mini Lite Brake Rotor
  [Rims must that have 2″ backspace]
• Douglas Wheel, Van-K, and other American Racing Rims
• Vevor Wheels / Metric Rims
• Yard Kart [single wheel drive or single wheel brake]

Options:

• 5/8″ ID Bearings
• 1/4-28 Bolt Kit
• 5/16-24 Bolt Kit
• M8 Bolt Kit
