“Eagle Elite” Go-Kart Frame from Liberty Karts Heavy Duty Frame

Description

Product Specs:

• Liberty Karts; The Eagle Elite Go Kart Frame
• Made in USA
• Heavy Duty frame fabricated with 1x1x14 gauge square tube
• Engineered for easy assembly
• Accepts up to a 23 HP engine
• Riders up to 450 lbs.
• Compatible with clutch or torque converter
• Raised engine mount for more clearance (larger sprockets)
• Special 3″x 6″ logo cutout welded on back of frame
• 3 bolt bearing hangers for 1″ live axle
• Spring suspension spindle brackets (springs not included)
• Upper & lower adjustable steering shaft mounts
• Throttle & brake pedal mounts
• Throttle & brake cable mounts
• Reinforced rear steering shaft mount
• Triple reinforced universal engine mounting plate
• Seat belt mounting plates
• Universal seat mounts, almost any seat will fit (go-kart, lawnmower, tractor, boat, car, etc.)
• Jig welded
• Square tube end caps for installation after painting is completed
• AWS certified
• Frame will be new unpainted steel (may have some surface rust)
• Approximately 26″x 60″ x 8-1/2″ (70 lbs.)
• Some drilling required

Parts Included:

• Welded main frame
• Upper/lower steering shaft mounts
• Seat mounts
• Square tube end caps

Shipping Option:

• Available to ship to the Continental United States (no Alaska or Hawaii)
• Choose your state of delivery for accurate shipping cost.
• Ships via UPS Ground only
