MSD Pro Power HVC Ignition Coil 45000V Red 8251

Description

The MSD Pro Power HVC 8251 ignition coil delivers 45,000 volts of raw ignition energy to maximize spark intensity and engine response in high-RPM racing environments. Built with an efficient E-core design, this coil produces more voltage and current while running cooler than conventional canister coils—critical for sustained drag racing and long-duration competition. If you’re running an MSD 7 or 8 Series ignition control and need reliable, consistent spark output under extreme conditions, this coil is engineered to perform where it matters most.

• 45,000 volt maximum output
• E-core winding design
• 85:1 turns ratio
• 0.040 ohm primary resistance
• 1.1 amp peak current
• 150 microsecond spark duration
• 86 ohm secondary resistance
• 1 mH inductance
• Red epoxy windings
• Spark plug style terminal
• Threaded brass studs
• Extruded bracket mounting
• Rubber shock mounts included
• Drag race optimized
• MSD 7/8 Series compatible
• Bolt-on installation
