X-Maxx Ultimate Brushless Monster Truck

Description

Features:

• High Performance Aluminum Upgrades
• VXL-8s™ Waterproof Electronic Speed Control
• Velineon® 1200XL Brushless Motor
• 50+ MPH with Two 4s LiPo Batteries and Optional Gearing (sold separately)
• Traxxas Stability Management® (TSM)
• TQi™ 2.4 GHz 2-Channel Radio System with Wireless Module
• Clipless Body Mount System
• 8s Driveline – Full-time shaft-driven 4-wheel drive
• Fixed Motor Mounting System on rigid aluminum motor mounts
• Heavy-Duty Modular Composite Chassis with interlocking front and rear bulkheads
• Snap-Lock Battery Retention System
• Front energy absorbing rubber impact bumper and lower front and rear skids for impact and abrasion resistance
• 6061-T6 aluminum steering bellcranks
• 2085RL high-output metal-gear steering servo
• TUBES 7075-T6 Aluminum front toe links
• Aluminum GTX™ Shocks with machined aluminum threaded body
• Massive 8.4? Sledgehammer® belted tires

Specifications:

• Name: X-Maxx Ultimate
• Model Type: Monster Truck
• Top Speed: 50+ mph with two 4s LiPo batteries and optional speed gear (sold separately)
• Skill Level: 6
• Scale: X-Truck®
• Motor: Velineon® 1200XL (1275 Kv sensorless brushless)
• Electronic Speed Control: Velineon® VXL-8s™ Brushless
• Weight: 22.20 pounds (9.5 kg)
• Length: 30.67 inches (779 mm)
• Width: 21.3 inches (540 mm)
• Track: 21.3 inches (540 mm)
• Height: 13.99 inches (355 mm)
• Wheelbase: 18.92 inches (480 mm)
• Center Ground Clearance: 4.2 inches (107 mm)
• Driveline: Shaft-driven 4WD
• Transmission: Single speed
• Differential Type: Sealed, hardened steel bevel, limited slip
• Gear Ratio (Internal): 8.11 (stock, out-of-box)
• Gear Pitch: 1.0 metric pitch (Mod 1)
• Steering Servo: 2085RL metal gear ultra-high-torque waterproof
• Radio System: TQi™ 2.4 GHz 2-channel transmitter with wireless module
• Battery Compartment Specs: 197 mm X 52 mm X 44 mm

What’s In The Box:

• X-Maxx Ultimate, Ready-To-Race model with Traxxas Big Block™ brushless motor
• VXL-8s waterproof electronic speed control with integrated telemetry
• TQi 2.4 GHz radio system with factory-installed wireless module
• Quick Start Guide
• High quality maintenance tools

What You’ll Need:

• LiPo Battery: Traxxas recommends dual 4-Cell, 6700 mAh Power Cell LiPo batteries (part 2890X) or the Dual 4s Completer Pack (part 2997)
• Charger: 4s LiPo Balance Charger with iD®
• AA Alkaline Batteries: (4) AA alkaline batteries for the transmitter
